Specification
Technical data
| Property | Value |
|---|---|
| Input voltage | 10 - 30 V DC |
| Inputs | 6 |
| Outputs | 6 (non-dimmable) |
| Output switching type | positive switched |
| Total current | 60 A |
| Current consumption (quiescent current) | 35 mA |
| Current per output | 15 A |
| Output fuses | automotive blade fuse (ATO) |
| System fuse | max. 2 A |
| Vin terminal | 0.5 - 35 mm² |
| Push button terminal | 0.2 - 6 mm² |
| Output terminal | 0.2 - 6 mm² |
| Degree of protection | IP20 |
| Bluetooth | included |
| CAN bus | included |
| Connection direction | from below |
| Operating temperature | -20 °C to +50 °C |
| Dimensions (L x W x H) | 14.5 cm x 11.7 cm x 5 cm |
Installation and ambient conditions
| Property | Value |
|---|---|
| Permissible mounting orientation | any |
| Installation location | dry, clean, mechanically suitable |
| Cable strain relief | required |
| Mounting on readily flammable materials | not permitted |
Manufacturer and registration details
| Property | Value |
|---|---|
| Manufacturer | Flextronic GmbH |
| Address | Mehrstedter Str. 3, 99994 Nottertal-Heilinger Höhen OT Schlotheim, Germany |
| Contact | service@flextronic.net |
| CE marking | present |
| RoHS compliance | compliant |
| WEEE reg. no. | DE 55988634 |
| CE | Grüner Punkt | WEEE |
|---|---|---|
 |
 |
 |
